Water Suction Hose
Water Suction Hose
Water suction hose is a flexible rubber water hose. It is ideal for both the suction and discharge work. Because it can bear both positive and negative pressure.
Suction Rubber Hose Structure
Tube: Black, smooth, NR or SBR
Reinforce: Multiply of high strength
synthetic fibres and helix steel wires
Cover: Black, smooth, cloth impression, SBR
Temperature: -30℃ to +80℃(-22℉ to +176℉)
Rubber Water Suction Hose is a versatile hose with steel wire and textile reinforcement. This hose is suitable for medium and heavy duty discharge applications with durability and longevity. Different sizes, pressures and weights are available and rubber suction tube can be customized into max 24”.
Rubber Suction Hose Pipe can be used in many industries to transfer water, wastewater, non-critical chemical solutions, septic and other general fluids. Water suction hoses are built to handle more rigorous applications which can be subject to abuse, pressures or elements.
Water Suction Hose Features
- Weather and ozone resistant
- Anti-aging
- Flexible and light in weight
Water Suction Hose Application
Hardwall hose is designed for suction and discharge of water and non-corrosive fluids in constructions and light duty industrial applications. It’s ideal for rugged tough operating conditions
Water Suction Hose 150PSI Specification
| ID | OD | WP | BP | VACUUM | L | ||||
| inch | mm | mm | bar | psi | bar | psi | bar | m | ft |
| 3/4" | 19.1 | 30 | 10 | 150 | 30 | 450 | 0.8 | 60 | 200 |
| 1" | 25.4 | 36 | 10 | 150 | 30 | 450 | 0.8 | 60 | 200 |
| 1-1/4" | 31.8 | 44 | 10 | 150 | 30 | 450 | 0.8 | 60 | 200 |
| 1-1/2" | 38.1 | 51 | 10 | 150 | 30 | 450 | 0.8 | 60 | 200 |
| 2" | 50.8 | 64 | 10 | 150 | 30 | 450 | 0.8 | 60 | 200 |
| 2-1/2" | 63.5 | 77 | 10 | 150 | 30 | 450 | 0.8 | 60 | 200 |
| 3" | 76.2 | 90 | 10 | 150 | 30 | 450 | 0.8 | 60 | 200 |
| 3-1/2" | 88.9 | 104 | 10 | 150 | 30 | 450 | 0.8 | 60 | 200 |
| 4" | 101.6 | 118 | 10 | 150 | 30 | 450 | 0.8 | 30 | 200 |
| 5" | 127 | 145 | 10 | 150 | 30 | 450 | 0.8 | 30 | 100 |
| 6" | 152.4 | 170 | 10 | 150 | 30 | 450 | 0.8 | 30 | 100 |
| 8" | 203.2 | 224 | 10 | 150 | 30 | 450 | 0.8 | 30 | 100 |
| 10" | 254 | 276 | 10 | 150 | 30 | 450 | 0.8 | 12 | 40 |
| 12" | 304 | 326 | 10 | 150 | 30 | 450 | 0.8 | 12 | 40 |
| 14" | 350 | 378 | 10 | 150 | 30 | 450 | 0.8 | 12 | 40 |
Water Suction Hose 300PSI Specification
| ID | OD | WP | BP | L | ||||
| inch | mm | mm | bar | psi | bar | psi | m | ft |
| 3/16" | 4.8 | 12 | 20 | 300 | 60 | 900 | 100 | 330 |
| 1/4" | 6.4 | 13 | 20 | 300 | 60 | 900 | 100 | 330 |
| 5/16" | 7.9 | 15 | 20 | 300 | 60 | 900 | 100 | 330 |
| 3/8" | 9.5 | 16 | 20 | 300 | 60 | 900 | 100 | 330 |
| 1/2" | 12.7 | 22 | 20 | 300 | 60 | 900 | 100 | 330 |
| 5/8" | 15.9 | 26 | 20 | 300 | 60 | 900 | 100 | 330 |
| 3/4" | 19.1 | 29 | 20 | 300 | 60 | 900 | 100 | 330 |
| 1" | 25.4 | 36 | 20 | 300 | 60 | 900 | 100 | 330 |
| 1-1/4" | 31.8 | 44 | 20 | 300 | 51 | 750 | 60 | 200 |
| 1-1/2" | 38.1 | 51 | 20 | 300 | 51 | 750 | 60 | 200 |
| 2" | 50.8 | 65 | 20 | 300 | 51 | 750 | 60 | 200 |
| 2-1/2" | 63.5 | 78 | 20 | 300 | 51 | 750 | 60 | 200 |
| 3" | 76.2 | 91 | 20 | 300 | 51 | 750 | 60 | 200 |
| 3-1/2" | 88.9 | 108 | 20 | 300 | 51 | 750 | 60 | 200 |
| 4" | 101.6 | 120 | 20 | 300 | 51 | 750 | 60 | 200 |
| 5" | 127 | 148 | 20 | 300 | 51 | 750 | 30 | 100 |
| 6" | 152.4 | 173 | 20 | 300 | 51 | 750 | 30 | 100 |
| 8" | 203.2 | 228 | 20 | 300 | 51 | 750 | 30 | 100 |
| 10" | 254 | 280 | 20 | 300 | 51 | 750 | 12 | 40 |
| 12" | 304.8 | 330 | 20 | 300 | 51 | 750 | 12 | 40 |
